• Model NO.：HPM5000A
• Controller：72V500A Brushless Controller
• Foot Throttle：Casted Alusmartum Foot Throttle
• Programm Kit：Setup Parameters Without Power-on Controller
• Gear Bridge：Optional
• High Power Li-on Battery：Optional
• Transport Package：Carton
• Specification：CE, ISO9001
• Trademark：Golden Motor
• Origin：China
• HS Code：85114099
• Production Capacity：2, 500 PCS,Year

Basic Info.

Model NO. HPM5000A Controller 72V500A Brushless Controller Foot Throttle Casted Alusmartum Foot Throttle Programm Kit Setup Parameters Without Power-on Controller Gear Bridge Optional High Power Li-on Battery Optional Transport Package Carton Specification CE, ISO9001 Trademark Golden Motor Origin China HS Code 85114099 Production Capacity 2, 500 PCS/Year

Product Description

High Power 5 Kw Electric Motorcycle Motor
High Power 5 Kw Electric Motorcycle Motor/5kw BLDC Motorbike Motor Max Speed: 85km/H (HPM5000A)
Drive Your Motorbike up to 100mph
Convert your gasoline powered motorcycle, scooter into electric version easily!
Clean, Quiet, Efficient, Light Weight, Monstrous Powerful, and Affordable.
1. Conversion Model:
The conversion model: 5KW BLDC Motor, Max Speed: 85km/h, Battery: 72V40AH Lithium, Range: 70km

2. Wire connection for Electric Motorcycle Kit

3. Pictue of BLDC Motor (10kw/5kw)

4. Here is the Form of Kit Contents

Item	Description
BLDC Motor (HPM5000A) Air Cooling	Voltage:24V/36V/48V/72V Rated Power:3KW-7.5KW Efficeincy: 88% Speed: 2000-6000rpm (customizable) Casing: AluSmartum Length (height): 126mm Diameter: 206mm Shaft: customizable Features: Compact design,Water resistent, Stainless Steel Shaft, Self Cooling Fan Applications: Electric car, electric motorcycle, electric tricycle, electric golf carts, fork lift, electric boat, etc.
BLDC Controller (For 5KW Motor)	Type: HPC300H Series(For 5KW Motor) Voltage Range:48V/72V/96V Rated Current (Max):360A/300A/240A Weight:2.2Kgs Dimensions:192x146x77mm Features: Programmable via USB port, Fuse breaker, Regen Braking, Temperature sensoring
Contactor	to protect the controller
Spare Wiring Harness	Model: CA-201 -- HPC Controller Wiring Harness 23-pin Water-Resistent Connector Dynamic Montoring Connector
Program Kit	Model: PI-400 -- HPC Controller Programming Kit Easy Installation for PC/laptop with Windows OS Easy USB Port Connection Setup Parameters without Power-on Controller Monitor Motor Performance Dynamically
Foot Throttle	Model: FSC-010 -- Foot Throttle Output Voltage: 0-5V Material: casted aluSmartum Features: Water resistent
