• Model NO.：GLP10Ah-7768256
• Keywords：Power Lithium Battery
• Battery Material：Nmc Cathode Material
• Transport Package：as Customer Request
• Specification：76*107*380mm
• Trademark：eastar
• Origin：China
• HS Code：8506109000
• Production Capacity：10000000

Cell

model

GLP10Ah-7768256

Capacity(0.5C)

≥10Ah

rated voltage(V)

3.2V

Typical Impedance (mΩ)

≤5mΩ

Battery material

NMC cathode material

PACK

Combination method

1P12S

Minimal capacity(0.5C)

10Ah

Nominal voltage

36V

Max. charge voltage

43.8V

Discharge cut-off voltage

≤30V

Max Charge current

5A(0.5C)

Max Working current

15A(1.5C)

Standard charge current

0.3C

Standard charge current

0.5C

Pack Impedance standard

≤100mΩ

Weight (Approx.)

4.2Kg

Max. dimension(L×W×H)(mm)

76*107*380

Operating  temperature

Charge temperature

0ºC~45ºC

Discharge temperature

-20ºC~60ºC

 BMS

Single cell over-charge cut-off voltage

3.7V

over-charge release voltage

3.6V

Single cell under-discharge cut-off voltage

2.5V

Discharge release voltage

2.7V

Over-discharge cut-off current

40A

Over-discharge cut-off current delay

1.5S

Short-circuit protection

100A

Short-circuit protection delay

500uS

Condition for the recovery of over-current and Short-circuit

Balance current

40-50mA

Balance Condition

3.6

Caution:

1.Do not dismantle, open or shred the batteries.

2.Do not expose batteries to heat or fire. Avoid storage in direct sun light.

3 .Do not short-circuit the battery,Do not store batteries haphazardly in a box or drawer where they may be short-circuited by other metal objects.

4 Forbid confusedly using the charge socket and discharge socket, or accidents may occurred.

5.Do not subject batteries to mechanical shock.

6.In the event of a cell leaking, do not allow the liquid to come in contact with the skin or eyes. If contact has been made, wash the affected area with copious amounts of water and seek medical advice.

7.Observe the plus (+) and minus (-) marks on the battery and equipment and ensure correct use.

8.Keep batteries out of the reach of children.

9.Keep batteries clean and dry.

10.Wipe the battery terminal s with a clean dry cloth if they become dirty.

11 .Batteries need to be charged before use. Always use the correct charger and refer to the manufacturer's instructions or equipment manual for proper charging instructions.

12.Do not leave a battery on prolonged charge when not in use.

13 .After extended periods of storage, it is necessary to charge and discharge the batteries several times to obtain maximum performance.

14 .The batteries give their best performance when they are operated at normal room temperature (20 °C ± 5 °C).

15.Retain the original product literature for future reference.

16.Use only the battery in the application for which it was intended.

17 When possible, remove the battery from the equipment when not in use.

18. Dispose of properly.

19. Cells used as E-motor or storage power should be matched with controller or related equipment..Because the battery piles are matched with protection board,you can not drive the pure inductance equipment otherwise you could damage the whole system.
