FH-80 Bicycle Engine Kit / 80cc Bike Engine Kit / Black Color
B.T. Motor Factory- Type：Cooling System
- Start：Kick
- Cylinder NO.：1 Cylinder
- Stroke：Two Stroke
- Cold Style：Air-Cooled
- Energy Transformation：Power Machine
Base Info
- Model NO.：FH-80
- Certification：ISO9001：2000
- Main Market：South America
- Transport Package：Carton
- Trademark：Flying Horse
- Origin：China
- HS Code：8407909090
- Production Capacity：50000,Year
Description
Basic Info.
Model NO. FH-80 Certification ISO9001：2000 Main Market South America Transport Package Carton Trademark Flying Horse Origin China HS Code 8407909090 Production Capacity 50000/YearProduct Description
FH-80 engine is designed and produced by flying horse factory . This engine is updated model of F80 model .
This new model have 40mm intake ports and wide front mount port suitable for big frame.
The advantage of FH-80 is its reliable quality of the main parts of the engine and the good assembling work .
Product Specification
Engine Type: 2021 Year FH-80/ 80CC Engine
Intake Ports: 40mm
Bore & Stroke: 47mm x 40mm
Max Power: 2KW, 5000R/MIN
Compression Ratio: 7:1
Ignition: CDI
Start: Kick Start
Tank Size: 2 Litres
Fuel Consumption: 2.5-3.5L/100Km
Speed: up to 50KM/Hr. Depending On bike size, weight & road Conditions
Type Of Clutch: Rub Bloc Drying
Fuel: Unleaded 91 PETROL Mixed with 2 stroke oil
Start : Kick Start
Tank Capacity: 2L
Lubrication Oil: Two Stroke Oil
Max Speed: 45km/h - 55 km/h
Mixing Ratio of Fuel and Engine oil: 20:1 for new set, 25:1 after 500km
Package included as below
| SN | Description | Qty |
| 1 | 2021 Year 2 Stroke FH-80/80CC MOTOR | 1 |
| 2 | Speed careburetor | 1 |
| 3 | Fuel Line | 1 |
| 4 | Fuel Filter | 1 |
| 5 | Gas Tank Switch-Male Type | 1 |
| 6 | 2L Gas Tank | 1 |
| 7 | Twist Throttle And Grip | 1 |
| 8 | Throttle Cable | 1 |
| 9 | Clutch Lever | 1 |
| 10 | Clutch Cable | 1 |
| 11 | Large Spring (Heat Shield Spring) | 1 |
| 12 | Extension Spring (Recoil Spring) | 1 |
| 13 | CDI Electron Ignition Coil- High Quality | 1 |
| 14 | Spark Plug and its tool | 1 |
| 15 | Chrome Muffler With Heat Shield | 1 |
| 16 | Outlet Gasket-High Quality | 1 |
| 17 | Big Clamp For Muffler | 1 |
| 18 | Small Clamp For Muffler | 1 |
| 19 | Heavy Duty 415 Chain- High Quality | 1 |
| 20 | Chain Idler With Bearing | 1 |
| 21 | Zinc 44T Sprocket | 1 |
| 22 | Sprocket Clamp Kit | 1 |
| 23 | Engine Mount | 1 |
| 24 | Front Engine Clamp | 1 |
| 25 | Rear Engine Clamp | 1 |
| 26 | Big Engine Clamp Used For Big Frame Tube | 1 |
| 27 | Bolts, Washers and Nuts | 1 |
Notes:
1. U Bracket is not included.
2. Intake Ports: 40MM
3. Package Size: 41*37*18CM
4. G.W. Per Package: 11.2KGS
