Ww-2108 Wave125 Motorcycle Parts Damper Shock Absorber
XINGTAI WINWAY IMPORT & EXPORT TRADING CO., LTD.- Position：Rear
- Working Substance：Spring
- Structure：Telescopic-tube Front Fork Hydraulic Shock Absorber
- Certification：ISO9001
- Load Adjusting Method：Spring Initial Pressure Regulating Type
- Hydrocylinder Working Position：Regular Type
Base Info
- Model NO.：WAVE125
- Damping Force Direction：One Way Direction
- Applicable Motorcycle：Wuyang Honda
- Working Cylinder Diameter：56.5
- Brand：Winway
- Model：Wave125
- Key Words：Shock Absorber
- Colour：Yellow
- OEM：5240A-Ktm-850zb
- Ultimate Load：200 Kgs
- Absorber Spring Material：60si2mna
- Durability：More Than 1 Million Stoke
- Raw Material：Solid Steel
- Inner Package：Colourful Box
- Main Market：South America, Middle East, Africa
- Transport Package：Colorful Box
- Specification：SGS
- Trademark：WINWAY
- Origin：Hebei
- HS Code：8708809000
- Production Capacity：2000PCS,Week
Description
Model
WAVE125
Applicable
Brand
WINWAY
Material
Iron/Aluminum
Packing
Box
Central distance
330mm
Upper axle hole diameter
21×10
Lower axle hole diameter
21×10
| Item Name | Motorcycle rear shock absorber |
| Progressive-rate Coil Spring | Oil Pressure |
| Adjustable Preload | Compression Damping |
| Absorber spring material | 60si2MnA |
| Ultimate load | 200 kgs |
| Forged Aluminum Body | Hard Chrome Piston Rod |
| Customized Design&Size | Available |
| Material | Aluminum & Solid Steel |
| OEM | Acceptable |
| Mixed Container | Acceptable |
| Package Details | Small Box+Cartons |
| MOQ | 100 Pairs |
| Loading Port | Tianjin/Shanghai |
| Delivery detail | 25days,after order confirm |
| Payment term: | T/T or L/C |
| Main market | Middle east,Africa,South America |
(1)A complete range of specifications and a great variety of models.
(2)Durable in use and dependence performance.
(3)Sincere service and prompt shipment.
(4) Competitive price and excellent performance.
(5)Can adapt to customer's specific request and also can make new model according to your samples or designing draft.
The spring adopts material of high quality steel, has excellent anti-fatigue performance, screw plated by hard chrome, anti-tension strength reaches 800Mpa or above. The oil seal adopts imported rubber with special preparation. Function is very good, with 2.5 million times of non-over-block usage.
Shock Absorber Material and Quality
1. Spring: high quality spring steel 60si2MnA,to have degree of fatigue resistance
2. piston rod: Mirror-surface treatment,Hard chrome plated,made the tensile strength and compressive strength above 800 Mpa.
3. oil seal: protect oil in cylinder and dust out cylinder at high temperture
4. Absorber oil : good performance of resistance to abrasion and rust resistance in different temperature conditions.
5. Damping grease: good damping force performance,anti frication in both high and low temperature situation
Quality Guarantee
1.A complete range of specifications and a great variety of models.
2.Durable in use and dependence performance.
3.Sincere service and prompt shipment.
4.Competitive price and excellent performance.
5.Adapt to customer's specific request and also can make new model according to your samples or designing draft.
Xingtai Winway Import and Export trading CO., LTD
ADD: 176#Kaiyuan Road, Qiaodong District, Xingtai City, Hebei, P. R. China
Web: xtwinway.en.made-in-china.com
| WAVE125 | |
| packge | colorful box |
| delivery date | 20days |
