• Model NO.：YB12AL-BS (GEL)
• Working Life：18 Months
• Certification：CE, UL, SONCAP, SASO, Inmetro
• Color：Orange
• Terminal：Lead Alloy
• Delivery Time：1 Month
• Volts(V)：12
• Cpapcity(Ah)：12
• Hourly Rate(Hr)：10
• CCA/-18ºC：160
• Do Not Contain Acid Weight：3.63
• Terminal Type：Z1
• Regular Charging Current(a)：1.2
• Carton Packing(PCS)：8
• Assembly Figure：- +
• Meter CCA(25+-5ºC)：250
• Transport Package：Export Sandard Packaging
• Specification：134*78*156mm
• Trademark：OUTDO
• Origin：China,Thailand
• HS Code：8507100000
• Production Capacity：1200000 PCS,Month
• Package size per unit product：134.00cm * 78.00cm * 156.00cm
• Gross weight per unit product：3.630kg

Basic Info.

Model NO. YB12AL-BS (GEL) Working Life 18 Months Certification CE, UL, SONCAP, SASO, Inmetro Color Orange Terminal Lead Alloy Delivery Time 1 Month Volts(V) 12 Cpapcity(Ah) 12 Hourly Rate(Hr) 10 CCA/-18ºC 160 Do Not Contain Acid Weight 3.63 Terminal Type Z1 Regular Charging Current(a) 1.2 Carton Packing(PCS) 8 Assembly Figure - + Meter CCA(25+-5ºC) 250 Transport Package Export Sandard Packaging Specification 134*78*156mm Trademark OUTDO Origin China/Thailand HS Code 8507100000 Production Capacity 1200000 PCS/Month

Packaging & Delivery

Package size per unit product 134.00cm * 78.00cm * 156.00cm Gross weight per unit product 3.630kg

Product Description

Characteristic of Valve Regulated

GEL Battery

1. 100% Pre-delivery inspection to ensure stable quality and reliable performance
2. Pb-Ca grid alloy battery plate, low water loss, and stable quality low self-discharge rate.
3. Complete sealed, maintenance free, low self-discharge rate, good sealing property.
4. Low internal resistance, good high rate discharge performance
5. Excellence high-and-low temperature performance, working temperature ranging from -40ºC to 60ºC.
6. High charge retention, long cycle service life
7. Design float service life: 3-5 years.



Safe Use Precautions



Warning

1. The inside electrolyte will corrode metal, cotton product, stone. Use properly.
2. Do not place the battery against the side or upside down to prevent acid leakage
3. The hydrogen will be generated during the working and discharging of battery which will cause explosion if there were fire. Pay attention for the following
3.1. Maintain and use the battery where is ventilate
3.2. No sparks and flame when the battery is in maintenance
3.3. If the battery is charging outside the vehicle which can't be installed immediately after finish charging until laying at lease 10min to release the hydrogen generated inside
the battery.
3.4. After riding, the battery can't be dismounted immediately until laying for at least 10 mins
3.5. During charging, the ambient temperature should not be over 45ºC, Otherwise cooling by water or by reducing the charging current and charging volts.
4. DO NOT place the metal tool or conducting matter nearby the terminal in case short-circuit the terminal
5. DO not knock the terminal by hammer during the battery installation
6. Be safe during carrying to prevent hitting



Installation and Maintenance

1. Always connect the positive terminal firstly.
DO NOT reverse polarity otherwise the electrical equipment of motorcycle will damage.
Caution:
*Some can't be activated due to the different performance of different vehicle. Start the engine for more times or step on gas which can more easily to activate.
*Manual activation is recommend to achieve exact date recorded.
2. During acid filling, wearing acid-proof cloths, rubber boots, shield glass and rubber glove etc.
If the skin and clothes are splashed by acid, wash by large quantity of water. Seek medical help if necessary.
3. DO NOT over discharging the battery, charging the battery timely after discharging.
4. Dismount or disconnect the negative terminal of battery if the motorcycle hasn't been in service for long term.
5. DO NOT check the battery has power or not by short-circuit the terminal.
6. Regularly check the terminal connection and the surface of terminal is clean or not to ensure well connection.
7. Storage the battery where is 5~25ºC, dry, ventilated and no direct sunshine. Keep the battery at least 2m away from the heat source. Regularly check and maintain the battery.

CONTACT US

Zhangzhou Huawei Power Supply Technology Co., Ltd.
Add: Industrial District of Lieyu Town, Yunxiao County, Zhangzhou, Fujian, China
Postcode: 363300

Web: http://huawei-battery.en.made-in-china.com

GENERAL INFO

√ Over 20 Years == √ Factory in China & in Thailand == √ Own Complete Industry Chain == √ Own Exporting License == √ Quality Control == √ Competitive Price == √ Own Technology == √ OEM==Short Delivery Time

PRODUCT INFO

√  Advanced absorbed glass mat technology
√  Complete sealed maintenance-free design
√  1-year free replacement warranty
√  Battery comes filled and fully charged before delivery
